Description
The Moving Bed module from the innovative ProfiClear Premium modular filter system for koi and other large ponds. In this module, original Hel-X biobodies ensure highly effective degradation of nutrients and pollutants using the fluidised bed method. The Hel-X biobodies, which originate from professional water treatment, offer microorganisms an extremely large protected colonisation surface (704 m²/m³). Thanks to the innovative bypass technology, they are optimally moved even at high flow rates. An aerator stone integrated into the module for connection to AquaOxy aerator pumps supplies the system with additional oxygen and keeps the Hel-X bodies moving at all times. The dirty water can be drained through the DN 70 floor drain with an integrated, high-quality slide valve. Discover the unique functions of the other modules too: Drum Filter Module and Individual Module. Trust in OASE quality, because you receive a total of up to 3 years guarantee – 2 plus 1 year requirement guarantee.
| Dimensions (L x W x H) | mm | 830 x 600 x 820 |
| Net weight | kg | 44.00 |
| Limited Warranty | Years | 2 + 1 |
| Biological filter surface | m2 | 47.8 |
| Biological filter surface protected | m2 | 40.3 |
| Temperature display | No | |
| Material | GRP Duroplast | |
| Number of inlets | Units | 2 |
| Inlet connections | mm | 180 |
| Inlet connections | 180 mm | |
| Number of outlets | Units | 2 |
| Outlet connections | DN 150 | |
| Sludge discharge connections | DN 75 | |
| Connection to | AquaOxy 2500 - 5000 | |
| Min. flow rate | l/h | 10000 |
| Max. flow rate | l/h | 33000 |
| Installation height above water level | cm | 11.5 |
| Type of use | Gravity fed system, Pump fed system | |
| Other | Aeration pre-installed incl. 50l Hel-X 13 Biomedia Pollutant discharge incl. slide valve |
